Conveyor Types:
Belt Type: Nylon/Polyester/Steel Cable/Cotton Canvas
Applied Material: Coal, Rock, Limestone, Ores, Minerals, Fertilizers, Bagged Material etc
Application: Mining, Coal, Metallurgy etc
The belt conveyors manufactured by ZK Corp mainly have the following types: please Click for detailed information.
1. It has features of large conveying capacity, long conveying distance, simple structure, stable running, convenient maintenance and easy operation.
2. Wide range of conveying material, it can convey wet, dry, powdery or lump material or packed product, loose materials and finished products in mine, metallurgy and coal industries.
3. Large conveying capacity and long conveying distance. It even can realize multi point load material and discharge
4. Conveyor length can be customized according to your need. Belt width can be 500-2400mm as your required.
Belt Conveyor is a friction-driven machine that continuously transports material. Our belt conveyor range encompasses the DTII fixed, DJ large-angle, and TD75 models. Engineered for reliable bulk handling, these conveyors are suitable for materials such as coal, rock, limestone, ores, and minerals, and are widely used in mining, coal, metallurgy, and related industries.
Please Click for the detailed information of different types.
Blow form is the specification of DTII Fixed Belt Conveyor.
|
Spec |
Rubber belt |
Length（m） |
Drive Drum Dia.(mm) |
Max. feeding size （mm） |
Capacity(m³/h) |
Power(kW) |
||
|
Width (mm) |
Speed(m/s) |
Slope (°) |
||||||
|
DTⅡ-500 |
500 |
0.8～2.5 |
0～20° |
2～240 |
400、500、630 |
100 |
69～217 |
1.5～30 |
|
DTⅡ-650 |
650 |
0.8～2.5 |
0～20° |
2～240 |
400、500、630 |
150 |
127～397 |
1.5～45 |
|
DTⅡ-800 |
800 |
0.8～3.15 |
0～20° |
2～240 |
400、500、630 |
200 |
198～781 |
2.2～75 |
|
DTⅡ-1000 |
1000 |
0.8～3.15 |
0～20° |
2～240 |
500、630、800 |
300 |
324～1622 |
7～100 |
Belt conveyor machine consist of conveyor frame, conveyor belt, conveyor pulley, conveyor rollers, tension devices, driving unit and other components etc.
