Model: XJ, SF, XCF, KYF, BF
Volume (m3): 0.35-100
Capacity (m3/min): 0.18-60
Application: mineral, magnesium production line
1. The suction intensity is big, the power loss is low.
2. Each trough has the suction, attracts the thick liquid and the flotation process function, from becomes the flotation process return route, does not need any supporting facility, the level disposition, is advantageous for the flow change.
3. The slurry circulation is reasonable, can maximum limit reduce the coarse sand precipitation.
4. Is equipped with the slurry surface automatic control and the electrically controlled installment, the adjustment is convenient.
Flotation equipment is mainly used for separating copper, zinc, lead
XCF/KYF Series Flotation Equipment
|
Model |
Volume (m3) |
Cell Size (mm) |
Impeller Dia. (mm) |
Impeller Speed (r/min) |
Capacity (m3/min) |
Power (kw) |
|
XCF/KYF |
1 |
1000x1000x1100 |
400/340 |
358/281 |
0.2-1 |
5.5/4/1.1 |
|
XCF/KYF |
2 |
1300x1300x1250 |
470/410 |
331/247 |
0.4-2 |
7.5/5.5/1.1 |
|
XCF/KYF |
3 |
1600x1600x1400 |
540/480 |
266/219 |
0.6-3 |
11/7.5/1.5 |
|
XCF/KYF |
4 |
1800x1800x1500 |
620/550 |
215/200 |
1.2-4 |
15/11/1.5 |
|
XCF/KYF |
6 |
2050x2050x1750 |
620/550 |
215/200 |
3-6 |
15/11/1.5 |
|
XCF/KYF |
50 |
4400x4400x3500 |
1200/1030 |
134 |
10-40 |
90/75/1.5 |
|
XCF/KYF |
70 |
5100x5100x3800 |
1120/1120 |
121 |
13-50 |
90/90/1.5 |
|
XCF/KYF |
100 |
5900x5900x4200 |
1260/1260 |
|
20-60 |
132/110/1.5 |
BF Series Flotation Equipment
|
model |
Volume(m3) |
Cell size(mm) |
Impeller Dia.(mm) |
Capacity(m3/min) |
Power(kw) |
|
BF-0.37 |
0.37 |
740x740x750 |
286 |
0.2-0.4 |
1.5/1.1 |
|
BF-0.65 |
0.65 |
850x950x900 |
300 |
0.3-0.7 |
3/1.1 |
|
BF-1.2 |
1.2 |
1050x1150x1100 |
450 |
0.6-1.2 |
5.5/1.1 |
|
BF-2.0 |
2 |
1400x1450x1120 |
500 |
1-2 |
7.5/1.1 |
|
BF-2.8 |
2.8 |
1650x1650x1150 |
550 |
1.4-3 |
11/1.5 |
|
BF-4 |
4 |
1900x2000x1200 |
650 |
2-4 |
15/1.5 |
|
BF-6 |
6 |
2200x2350x1300 |
700 |
3-6 |
18.5/1.5 |
|
BF-8 |
8 |
2250x2850x1400 |
760 |
4-8 |
30/1.5 |
|
BF-10 |
10 |
2250x2850x1700 |
760 |
5-10 |
30/1.5 |
|
BF-16 |
16 |
2850x3800x1700 |
850 |
8-16 |
37/1.5 |
|
BF-20 |
20 |
2850x3800x2000 |
850 |
10-20 |
37/1.5 |
|
BF-24 |
24 |
3150x4150x2000 |
920 |
12-24 |
45/1.5 |
The tank is made as u type, reducing sand settlement to the least .Due to reasonable design of the impeller structure and the impeller space, impeller wearing is even. So the service life of the impeller and stator are extended. Model KYF is unable to spontaneously suck slurry, while has low power consumption. In contrast, model XCF has the ability to automatically suck slurry, and may be allocated horizontally without needing foam pump, but consumes more power than model KYF. Therefore, model XCF and model KYF are combined into a set, such as XCF as the sucking tank, and KYF as the direct tank. The combined set can be arranged horizontally without foam pump either.
